High Temperature Thermocouple

High Temperature Thermocouple

Thermocouple temperature probe for high temperature working cycles

The thermocouple with ceramic measuring sheath is ideal for high temperature processing cycles in the glass, steel, ceramics and incinerator industry.

Common or noble metal construction for the various measuring ranges required, with possible threaded or flanged process connections.

Contact us

ASTC-G model

Type B, R, S, K, J, N. Other types on request
Tolerance class 1 or 2 according to CEI EN60584-1, Standard or Special according to ASTM E230
Hot junction: isolated
Simple isolated execution by two-wire/square-wire ceramic or mineral oxide thermocouple insert (MgO)
Single or double ceramic protection
Sheath material ceramic: C610, C799
Diameter of ceramic sheath ranging from 6 to 20 mm
Sleeve in SS 304, 310, 316, 446, Inconel600
Sleeve length on request
Aluminum connection head
Ceramic terminal block or temperature transmitter with 4..20 mA output (HART protocol on request)
Fixed or sliding fittings
Possibility of having a sliding flange on the sleeve
